Sentera & Inspired Flight RTK/PPK Module
Unlock Survey-Grade Precision for Your Inspired Flight Drone
The Sentera RTK/PPK Module enhances Inspired Flight Technologies (IFT) drones with centimeter-level GNSS precision for aerial surveying and mapping. Designed for seamless integration, this NDAA-compliant module provides real-time (RTK) and post-processed (PPK) corrections, ensuring survey-grade accuracy across diverse applications.
Key Benefits
-
Industry-Leading Accuracy: Achieve 1 to 3 cm precision for survey-grade data collection, reducing reliance on ground control points and improving efficiency.
-
Seamless Workflow Integration: Exclusively compatible with Inspired Flight aircraft and Sentera sensors for hassle-free data capture and processing.
-
Dual RTK & PPK Flexibility: Choose real-time RTK corrections for live precision or post-processed PPK workflows for maximum accuracy in complex environments.
-
Plug-and-Play Simplicity: Quick installation with minimal setup and in-app feedback for real-time monitoring.
-
Multi-Constellation GNSS Support: Strong satellite connectivity in challenging conditions using GPS, GLONASS, Galileo, and BeiDou.
-
Regulatory Compliance & Security: NDAA-compliant hardware ensures secure, reliable performance for government and commercial applications.
Key Features
-
Exclusive compatibility with Inspired Flight aircraft, integrates with Sentera sensors
-
1 to 3 cm RTK/PPK accuracy for survey-grade applications
-
L1/L2 dual-frequency GNSS with multi-constellation support
-
PPS synchronization for precise image-to-GPS alignment
-
Integrated Microhard P900 915 MHz radio module
-
Low-power consumption for extended flight operations
-
NDAA compliant
Specifications
|
Parameter |
RTK/PPK Module |
|
Accuracy |
1 to 3 cm (RTK/PPK)* |
|
GNSS Frequencies |
L1/L2 Dual-Frequency |
|
Supported Constellations |
GPS, GLONASS, Galileo, BeiDou |
|
Synchronization |
PPS image-to-GPS alignment |
|
Radio Module |
Microhard P900 915 MHz |
|
Compliance |
NDAA-compliant |
|
Interfaces |
USB-C: Module to sensor interface USB-A: Module to 6X light sensor interface |
*Specifications are subject to change without notice. Accuracy may vary with processing methods and reference sources.
Compatibility
|
Category |
Models |
|
Inspired Flight |
IF800 Tomcat, IF1200 |
|
Sentera |
6X Series, 65R Series |
|
Base Stations |
Compatible with base stations that can provide an RTCM 3 or greater output via USB, Bluetooth, or Wi-Fi |
|
PPK Processing Software |
Propeller, Trimble Business Center, Emild Studio |
Key Use Cases
-
Surveying & Mapping: Capture high-accuracy topographical data.
-
Infrastructure Inspection: Pinpoint asset locations with confidence.
-
Environmental Monitoring: Detect landscape changes with precision.
Optimized for Surveying & Mapping
The Sentera RTK/PPK Module is designed to meet the needs of professional mapping, infrastructure inspection, and environmental monitoring. Its precision and reliability make it ideal for applications requiring consistent accuracy and dependable performance.
Seamless Integration with Inspired Flight Drones
Engineered for plug-and-play compatibility with Inspired Flight IF800 and IF1200 drones, the module delivers streamlined setup and intuitive in-app feedback.
Pair it with Sentera’s multispectral, RGB, or thermal sensors to capture industry-leading insights with survey-grade precision.
